Electrical
Battery
Lithium Ion Rechargeable, >3 hrs transport time (on full charge)
DC power
12V, 5A (wall adapter)
UPS functionality
Yes, automatic switching between Battery and DC power
Display
OLED, serial peripheral interface (fast refresh)
Environment sensing / performance
Temperature (4x), Relative Humidity (1x) , CO2 concentration (1x)
- Temperature accuracy +/- 0.5 degrees C
- Relative Humidity accuracy +/- 2%
- CO2 concentration +/- 0.5 %
Real-time operation sensing
Continuous device monitoring and notifications
- Gas cartridge presence
- Chamber Open / Close
- Gas pressure levels
- Battery levels
Actuation
Heating (2x), Gas injection (1x), Air pump (1x)
- Heating capacity 24 Watts
- Gas injection <100 milliseconds reaction time
- Air pump low powered / low noise
Communications
Integrated BlueTooth Low Energy , WiFi (802.11 b/g/n)
Embedded Processor
SoC embedded, dual-core 240 MHz
Onboard data storage
>3 days continuous recording (before overwrite)
Mechanical
Weight
5 lbs
Width
8.5 in
Depth
6 in
Height
7 in
Cartridge capacity
40 oz.
Cartridge life
>30 days (5% CO2 control)
Ambient temperature
Supports from 4 degrees C - 40 degrees C ambient temperatures
Note - Ambient temperature must be less than set-point temperature by >5 degrees C
Ambient RH
20-90 %RH (non-condensing)
Software control
Chamber environment
Chamber environment set-point control and thresholds for notification (see below)
- Set point temperature range to 4 degrees C - 45 degrees C
- Note - Ambient temperature must be less than set-point temperature by >5 degrees C
- Set point CO2 concentration range ~0 (atmospheric concentration) to 10%
Device modes
User configurable
- Isolated
- Local (BLE communication)
- Cloud (WiFi communication)
Application compatibility
CultureApp Mobile
CultureApp Cloud
CultureApp Desktop
Real-time data visualization
Yes
